Start 360°
4-Voice Polyphonic Analogue Synthesizer
- Limited special edition of the KORG minilogue
- 2 Voltage controlled oscillators (VCOs) with three waveforms each: sawtooth, triangle, rectangle
- 8 Different voice modes: POLY, DUO, UNISON, MONO, CHORD, DELAY, ARP, SIDE CHAIN
- Analogue filter, switchable between 2- and 4-pole operation (12 dB/octave or 24 dB/octave)
- 41 Permanently assigned knobs and switches for direct access to all sound-shaping parameters
- Cross modulation, ring modulation, oscillator sync
- 2 ADSR envelopes (EGs) for amp, filter and pitch (double assigned)
- 1 LFO (sawtooth, triangle, square)
- 200 sound presets (100 of which are factory preset, can be overwritten)
- 100 Special synth bass presets (original minilogue sounds can be loaded)
- 37 Velocity-sensitive slim keys in black and red
- 16-Step polyphonic sequencer with 4 tracks for motion sequencing
- Delay effect with high-pass filter
- Slider for controlling pitch bend or other modulations
- OLED display with real-time oscilloscope function
- Line output: 6.3 mm jack mono
- Line input: 63 mm jack mono
- Headphone output: 6.3 mm jack stereo
- Sync in/out: 3.5 mm mini jack mono
- MIDI I/O
- USB
- Black aluminium control panel with black swirl design
- Red coloured wooden back panel
- Black knobs with red markings
- Dimensions (W x D x H): 500 x 300 x 85 mm
- Weight: 2.8 kg
- Includes power supply DC9V (KA350)
Available since
February 2023
Item number
554980
Sales Unit
1 piece(s)
Number Of Keys
37
Touch-Sensitive
Yes
Aftertouch
No
Split Zones
No
Modulation Wheel
Yes
Number of simultaneous Voices
4
Sound Engine
Analogue
MIDI interface
1x In, 1x Out
Storage Medium
None
USB-port
Yes
Effects
Delay
Arpeggiator
No
Number of Analog Outputs
1
Digital Output
No
Display
Yes
Pedal Connections
None
Dimensions
500 x 300 x 85 mm
Weight
2,8 kg
