Zoom LiveTrak L6max
12-Channel Digital Mixer & Recorder
- 8 channels, each with 3-band equaliser, two aux sends, internal effect, panorama, level, mute button and encoder with LED ring
- 4 mono channels and 4 stereo channels
- Channels 1-4 with XLR/TRS combo jack for microphone and line signals (+48 V phantom power switchable)
- Channels 1 & 2 with Hi-Z switch for guitars and basses
- Channels 5-8 with 6.3 mm jack inputs for line signals and pad switches
- No levelling required thanks to 32-bit float converter technology
- Simultaneous recording of up to 12 mono tracks and stereo mix to microSD card (32-bit/48 kHz)
- AI-based noise reduction
- Unlimited overdubbing
- Integrated USB audio interface with 14 inputs and 4 outputs
- 4 sound pads that can also be used as loopers
- Internal effects processor with delay, reverb and compressor for the master output
- 4 Scene memories
- OLED display recording medium: microSDHC or microSDXC card up to max. 1TB (microSD card not included)
- USB-C port for audio, MIDI and data transfer
- MIDI In/Out: 3.5 mm TRS jack
- 2 x Aux Send: 6.3 mm jack
- Stereo master output: 2x 6.3 mm jack
- 2 stereo headphone output: 6.3 mm jack
- Power supply via USB-C port or 4x AA batteries (not included)
- Dimensions (W x D x H): 284 × 114 × 46.5 mm
- Weight: 673 g
- Includes USB-C cable and Zoom AD-17 power supply unit
-
Available since November 2025
-
Item number 625876
-
Sales Unit 1 piece(s)
-
Number Of Tracks 14
-
Simultaneous Recording: Amount Of Tracks 14
-
Effects Yes
-
Storage Medium microSDHC/SDXC
-
Phantom power Yes
-
XLR Connectors 4
-
Jack Connectors 12
-
RCA Connectors No
-
MIDI Interface In, Out
-
USB connection Yes
-
Digital Connections USB
-
Miscellaneous Connectors Lineout
-
Headphone connection Yes
-
Recording / Playback Channels 12x4
-
User Interface Physical
-
Number of faders 8
-
Number of Mic Inputs 2
-
Number of Line Inputs 12
-
DSP Input channels 12
-
Instrument Inputs 0
-
DSP Output Channels 4
-
Busses 2
-
Number of Line Outs 2
-
Headphone Outs 1
-
Number of Microphone Inputs 4
-
Number of Mono Line Inputs 4
-
Phantom Power Yes
-
Number of S/PDIF Connectors 0
-
Number of Stereo Line Inputs 4
-
Physical outputs 4
-
Number of ADAT Connectors 0
-
Digital stagebox connection No
-
Numer of AES/EBU Connectors 0
-
Ethernet 0
-
Number of MADI Connectors 0
-
Hotspot No
-
Word Clock No
-
Multitrack Record Yes
-
Other Connectors USB-C
-
Soundcard interface USB-C
-
MIDI interface Yes
-
Options Sound Pads, Scene Memory
-
integratated Player/Rec via USB/SD Multitrack
-
Recorder Format WAV
-
Max. Sampling Rate in kHz 48 kHz
-
Max. Resolution Rate in Bits 32 bit
-
RTA No
-
USB Bus-Powered Yes
-
Incl. power supply Yes
-
FX Processor 1
-
31 Band EQ 0
-
USB Version 2.0
-
Width 284 mm
-
Matrix 0
-
Depth 114 mm
-
Height 47 mm
-
DCA/VCA Groups 0
-
Sample rate 48 kHz
-
Separate Personal Monitor system No
-
Expansion Card slots 0
-
Digital ADAT No
-
Digital SPDIF Yes
-
Included in delivery Power Supply, USB-A to USB-C Cable
-
Digital AES3/ASESEB No
-
Zero latency monitoring Yes
-
Digital MADI No
-
Digital Dante No
-
Connection Format USB port Type C
-
Case No
-
19" Rackmount No
-
Weight 0,673 kg
-
Digital technology – analogue workflow
Building on the compact all-in-one approach of the LiveTrak L6, the Zoom LiveTrak L6max is designed for users looking to mix and record multi-track audio at the same time. Up to 12 separate tracks alongside a stereo mix can be captured simultaneously, directly to a microSD card, with support for 32-bit float recording at 48kHz. Features such as flexible tap point selection and built-in noise reduction allow recordings to adapt more easily to different environments and production needs. Additional Hi-Z compatible inputs broaden the range of connectable instruments, while the OLED display keeps essential recording and control functions close at hand. Its compact format remains unchanged, making it well suited to recording, rehearsals and streaming setups across a variety of flexible production situations.
)
Encoder-based channel control
The Zoom LiveTrak L6max is equipped with four combo XLR/jack inputs, including two Hi-Z connections designed for direct use with guitars and basses. Alongside these are four flexible stereo channels with a –20dB pad, two of which can also function as dual mono channels, while the remaining two operate as USB audio returns for routing signals from a computer straight into the mixer. Control is handled through encoders and selectable parameters, with LED rings providing a clear visual overview of levels and current settings. Each channel includes a 3-band EQ with adjustable midrange control, complemented by built-in effects such as reverb and delay, whose timing can be set quickly using the tap function. AI-supported noise reduction is also integrated, helping to reduce unwanted background noise in a range of recording situations.
)
Compact multitrack recording
The Zoom LiveTrak L6max is aimed at solo musicians, small bands, and content creators looking for a compact yet flexible production setup. Expanded connectivity options, including Hi-Z inputs for direct instrument connection, combine with freely selectable tap points that allow more precise control over signal routing within the recording chain. The unit also works well as a central hub for smaller recording, rehearsal and streaming environments where several audio sources need to be recorded and processed at the same time. Features such as 32-bit float recording, built-in noise reduction and unlimited overdubbing through a dedicated bounce track support a wide range of workflows, while helping to maintain consistent recording quality across different production conditions.
){kind=logo}
About Zoom
Founded in 1983, the Japanese company Zoom manufactures a variety of audio equipment, including a range of portable "handy" recorders as well as multi-effects processors, effects pedals, drum machines, and samplers. Over the past thirty years, the company has built a reputation for producing innovative yet affordable products based on original microchip designs. Since the Zoom-9002 (an ultra-compact multi-effects processor that can be attached to a guitar strap) was introduced in 1990, Zoom has become one of the leaders in digital audio processing.
Scenes, pads and monitor mix
The submix and monitor outputs make it possible to create two separate monitor mixes that operate independently from the main mix. Signal routing can be configured as pre-fader, pre-fader/post-comp or post-fader, allowing precise selection of the point within the signal chain where audio is tapped. Settings can then be stored across four scene memories for quick recall whenever needed. For additional creative flexibility, four built-in sound pads are included, suitable for triggering sound effects or working as loopers, with convenient MIDI control support. A range of power supply options further enhances portability, as the LiveTrak L6max can run via USB bus power, AA batteries or an external portable battery pack.
)
In the spotlight
L6 Editor App
The Zoom LiveTrak L6max can be configured via the L6 Editor app for Mac and Windows, where recording modes, battery type, sound pads, tap points, effects and MIDI assignments are adjusted through a structured and clearly organised menu system, allowing adaptation to different working scenarios. It also operates as a USB-C audio interface, providing 14 inputs and 4 outputs at up to 32-bit/48kHz resolution, which enables multi-channel recording and playback within a computer-based workflow. This makes integration into existing production environments straightforward, as multiple audio signals can be processed in parallel while remaining within a DAW setup.
)
